Holdvolt PS
Portable Power Stations, 145 Wh to 5.4 kWh
Battery, inverter and outlets in a carry case. Solar charging on every model.
- 8
- Models
- 145–5376Wh
- Battery capacity
Features
145 Wh – 5.4 kWh
Unit
- AC outlets
- USB / QC 3.0
- Solar input
- UPS function (large models)
Specifications
Factory catalog values, model by model.
Eight models
The smallest model has a modified-wave AC output.
| Model | PS-150 | PS-300 | PS-500 | PS-600 | PS-1000 | PS-3000 | PS-5000 | PS-2000H |
|---|---|---|---|---|---|---|---|---|
| Battery | ||||||||
| Battery / cell type | High quality lithium battery | High-Density High-Rate Battery | High quality lithium battery | High quality lithium ion battery | LiFePO4 | LiFePO4 | LiFePO4 | LFP |
| Battery capacity | 39000mAh, 3.7V / 145Wh | 288Wh / 78000mAh / 3.7V | 520Wh / 140400mAh / 3.7V | 520Wh / 140400mAh / 3.7V | 1008Wh / 3.2V 315,000mAh / 22.4V 45Ah | 2688Wh / 3.2V | 5376WH / 3.2V | LFP, 2048Wh±5% |
| Cycle life | >1000 times | >1000 times | >500 times | — | >2000 times | — | — | 3500 cycles |
| Input | ||||||||
| Recharging input (AC / DC) | DC15V/2A | DC15V/3.0A; High-Power Charging DC5521 13V-22V/3.0A | DC15V/6.0A | DC5521 12V-26V/8A MAX120W / Anderson 12V-26V/8A MAX160W / TYPE-C 5V-20V/3A MAX PD60W | DC 38V/6.0A | AC Input 1600W MAX | AC Input 1600W MAX | AC174-264V, 1600W Max; CAR Input DC12-24V/10A, 240W Max |
| Solar input | — | — | DC5521 13V–22V/6.0A | — | 12V-50V / MPPT MAX 350W | 650W 12-80V DC / 15A Max | 650W 12–80V / DC 8.5A Max | PV18-145V/25A, 1600W Max |
| Fully charged time | DC 15V: 6.5 hours | DC: 7-8 hours | DC: 8–9 hours | Single DC port charging: 4-5h / Single Anderson port charging: 4h / Single TYPE-C: 11-12h / Anderson port + TYPE-C port combination simultaneous charging: 3-4h / DC port + TYPE-C port combination simultaneous charging: 4-5h | DC 38V: 5 hours | AC input: 2.5 Hours | AC Input: 4 Hours | — |
| Output | ||||||||
| AC output | 200W, Modified Wave Output. / 110V (Build According to different nations) | 1X AC Inductive Discharge Output; AC Power Output 300W | 2x AC pure sine wave output; continuous 500W; peak 1000W | 2 x AC pure sine wave output; continuous 600W; Constant Power Output Voltage 650W (85V-120V (160V-230V)) | 4 x AC 230V/110V pure sine wave output; continuous 1200W | 4 x AC 230V/110V pure sine wave output; continuous 3000W | 4 × AC 230V / 110V pure sine wave output; continuous 3000W | Pure Sine Wave Output; AC Continuous Output 2200W; AC Max Output: [email protected] seconds, Voltage: 230VAC±10%, Frequency: 50Hz±5%; 3×3-pin-EU outlet |
| DC / USB output | USB 5V-3.1A(Max); DC 9–12.6V/10A, 120W(Max) | 1X USB 5V-9V/2A QUICK Charge 3.0 / 1X Type-C 5V-9V/2A QUICK Charge 3.0 / 2X USB 5V/2A / 1X DC 12V 10A (DC5521) / 1X DC 12V 10A (DC5525) / (Standard) 1X DC 24V 4A (DC5525) | 1 x USB 5V–9V/2A Qualcomm Quick Charge 3.0 / 1 x Type-C 5V–9V/2A Qualcomm Quick Charge 3.0 / 2 x USB 5V/3.1A (MAX) / 5 x DC 12V 10A | 1 * USB 5V-12V/2A, QC 3.0; 2 * USB 5V/3.1A; 1 * Type-c 5V-20V/3A; 4 * DC 13.5V/6A (5521); 1 * Cigarette Lighter adapter(13.5V/10A MAX150W) | 8 x USB Port: 5V/2A MAX / 2 x USB QC 3.0: 5V-9V/2A MAX 18W / 1 x Type-C Port: 5V-9V/2A MAX 18W / 1 x Type-C Port: 5V-20V PD 60W (Bi-directional charge/discharge) / 2 x 5521 DC output: 12V/10A (Regulated voltage) / 1 x Cigar output: 12V/10A (Regulated voltage) | 4 x USB QC 3.0: 5V-9V/2A MAX 18W / 2 x Type-C Port: 5V-15V/3A 20V 5A 100W MAX / 2 x 5521 DC output: 13.5V/10A (Regulated voltage) / 1 x Cigar socket: 13.5V/10A (Regulated voltage) | 4 × USB QC 3.0: 5V–9V/2A MAX 18W / 2 × Type-C Port: 5V–15V/3A, 20V 5A, 100W MAX / 2 × 5521 DC Output: 13.5V/10A (Regulated) / 1 × Cigar Socket: 13.5V/10A (Regulated) | 1x Cigarette Lighter 13.8V/12A Max; 2x DC Rated Output 13.8V/15A Max; USB-A1/A2 QC18W Max (QC3.0); USB-C1 PD100W Max (PD3.0); USB-C2 PD27W Max |
| Micro-inverter (on-grid) output | — | — | — | — | — | — | — | 200W/400W/600W/800W/2200W MAX, Adjustment of on-grid output power via APP (Choose or adjust according to local policies) |
| Other | ||||||||
| Lighting / wireless charging | LED (page title 'with LED Light') | Lighting 3W; Wireless Charging 5W | — | LED Lighting 4W; Wireless Charging 10W | — | — | — | Bulb 3W Max, 3 Levels (L/M/H)+SOS |
| Protection | — | Short circuit / Overcurrent / Overvoltage / Undervoltage (PA300: Overcharge, Overdischarge) / Overload / Over temperature protection | Short circuit / Overcurrent / Overvoltage / Undervoltage (PA300: Overcharge, Overdischarge) / Overload / Over temperature protection | Short circuit / Overcurrent / Overvoltage / Undervoltage (PA300: Overcharge, Overdischarge) / Overload / Over temperature protection | Short circuit / Overcurrent / Overvoltage / Undervoltage (PA300: Overcharge, Overdischarge) / Overload / Over temperature protection | Short circuit / Overcurrent / Overvoltage / Undervoltage (PA300: Overcharge, Overdischarge) / Overload / Over temperature protection | Short circuit / Overcurrent / Overvoltage / Undervoltage (PA300: Overcharge, Overdischarge) / Overload / Over temperature protection | Short-circuit protection, Over-current protection, Over-voltage protection, Low-voltage protection, Over-load Protection, Over-temperature protection |
| UPS function | — | — | — | — | — | — | page title 'with ups function'; table has no transfer-time spec | Charge While Discharge: Support |
| Expansion | — | — | — | — | — | — | — | Support up to 4 battery packs (10KWH); Support parallel connection of 4 hosts |
| Package included | 1 x Portable Power Generator / 1 x Power Adapter / 1 x Cigarette light adapter / 1 x Car charger / 1 x User manual | 1 X Portable Emergency Energy Storage Power Supply / 1 X User Manual / 1 X Charger | 1 x Portable solar generator / 1 x Power adapter / 1 x AC line / 1 x User manual / 1 x Car charger | 1 x portable solar generator / 1 x power adapter / 1 x AC line / 1 x user manual / 1 x Car charger | 1 x portable solar generator / 1 x power adapter / 1 x user manual | 1 x portable solar generator / 1 x AC line / 1 x user manual | 1 × Portable solar generator / 1 × AC line / 1 × User manual | 1xAC Power Cord-EU Standard, 1xXT60 TO CarCigarette Cable, 1xXT60 to MC4 Conversion Cable, 1x User manual |
| Environment | ||||||||
| Operating temperature | -10°C–40°C | -10°C – 40°C | -10°C–40°C | -10°C-40°C | -10°C-40°C | -10°C-40°C | -10°C to 40°C | 0°C–40°C |
| Physical | ||||||||
| Dimensions | 196x108x126mm (LWH) | — | — | — | — | — | — | L*W*H, 465*260*295mm |
| Weight | 1.5Kg | — | — | — | — | — | — | About 23kgs |
Factory values. Specifications may change; confirm against the quotation.Swipe the table sideways.
Questions buyers ask
What do you need for a quotation?
Load in kVA or kW, input voltage and phases, output phases, the backup time you need and where the unit will be installed. If you are unsure, send what you know and we will ask for the rest.
Can the unit carry our brand?
Yes. Logo, front panel, packaging and manual can be supplied under your brand. Minimum quantities and lead times are on the OEM / ODM page.
